| ابعاد | 32 × 127.8 × 182.8 میلی‌متر |
| وزن | 555گرم |
| رابط ها | پورت اترنت RJ-45 LAN , پورت RJ-11 |
| تعداد پورت اترنت RJ-45 | 4 |
| تعداد پورت RJ-11 | 1 |
| سرعت انتقال اطلاعات | 300 مگابیت بر ثانیه (300Mbps) |
| کلید ها | کلید خاموش یا روشن کردن دستگاه |
| تعداد آنتن | 2 |
| نوع آنتن | خارجی |
| قدرت آنتن | 5dBi |
| نشانگر LED | PWR, SYS, INTERNET, USB, WPS, WLAN, 4/iTV, LAN3, LAN2, 1/WAN, DSL |
| استاندارد های IEEE | ((Multi-mode, ANSI T1.413 Issue 2, ITU-T G.992.1 (G.dmt) Annex A, ITU-T G.992.2 (G.lite) Annex A, (ITU-T G.994.1 (G.hs |
| استاندار های ADSL | ITU-T G.992.3 (G.dmt.bis) Annex A/L/M ITU-T G.992.4 (G.lite.bis) Annex A |
| استاندار های ADSL2 | ITU-T G.992.5 Annex A/L/M |
| منبع تغذیه | آداپتور برق |
| ویژگی‌های نرم‌افزاری | ATM & PPP (ATM Adaption Layer type 5 (AAL5 Bridged or routed Ethernet encapsulation VC and LLC based multiplexing MAC Encapsulated Routing ATM Forum UNI3.1/4.0 PVC • ATM Cell Format ITU-T Rec. I.361 • (PPP over ATM (RFC 2364 (PPP over Ethernet (PPPoE (PPP Link Control Protocol (LCP (Internet Protocol Control Protocol (IPCP (PPP Authentication Protocol (PAP PPP Challenge Handshake (Authentication Protocol (CHAP Microsoft PPP CHAP extensions فایروال و امنیت دسترسی Built-in NAT firewall MAC Filtering Packet Filtering (Stateful Packet Inspection (SPI (Denial of Service prevention (DoS Intrusion Detection and Prevention System/Log User Authentication PAP User Authentication CHAP DMZ مدیریت Web-based GUI configuration 3-level login control for local/remote management 3-level login control for local/remote management • Firmware upgraded, configuration data uploaded and downloaded via Webbased GUI • TFTP for firmware, configuration files and image files upgrade and download TFTP server and client • Code Lock to prevent from improper firmware upgrade through UI, TFTP, and TR-069 (Local access via console (optional (Local access via console (optional • ADSL/ADSL2/ADSL2+ manual selection and auto fallback Auto VPI/VCI detection Configuration backup and restore Diagnostics Log & Trace function (SNMP v.1 and v.2c with MIB-I and MIBII (optional (TR-069 compliant with ACS (optional |
| سایر ویژگی‌ها | پروتکل ها Ethernet to ADSL Self-Learning Transparent Bridging (Internet Control Message Protocol (ICMP (Network Address Translation (NAT), IP Static Routing, Routing Information Protocol (RIPv1, RIPv2 Virtual Server, Port Forwarding NAT ALGs: MSN/AOL/Yahoo Messenger, FTP, CUSEEME, Real Audio, MIRC, SIP, ICQ, games, SNMP NAT ALGs: MSN/AOL/Yahoo Messenger, FTP, CUSEEME, Real Audio, MIRC, SIP, ICQ, games, SNMP (SNTP, DNS Relay, DDNS proxy and IGMP proxy (v1/v2/v3 گواهی نامه ها FCC Part 15 Class B / CE / CSA |
